Spray nozzles

The nozzle flow rate at gallons per minute (gpm). To find that, start with your application rate in gallons per acre (gpa). Next, find an efficient and safe ground speed in miles per hour (mph). Then, determine the spray width per nozzle (W).

A spray nozzle is a precision device that facilitates dispersion of liquid into a spray. A wide variety of spray nozzle applications use a number of spray characteristics to describe the spray. Spray nozzles can be categorized based on the energy input used to cause atomization, the breakup of the fluid into drops.

Full cone nozzles produce medium- to large-size drops forming a solid cone-shaped spray pattern with a round impact area. The unique vane design features large flow passages to provide superior control and uniform distribution. ... Spray angles range from 15° to 170°.
